UCT215-48, Take-Up Mounted Unit Bearing, 3 in Bore (ID), Insert Bearing: UC215-48, Housing: T215

Out of stock
SKU: UCT215-48
All of our mounted unit bearings are provided fully assembled. Should you require to receive insert bearing and housing separately, please contact us for assistance.
$99.99
Product details
  • Type Mounted Unit Bearings
  • Part Number UCT215-48
  • Housing T215
  • Insert Bearing UC215-48
  • Bore 3 in | 76.2 mm
  • Height 9.134 in | 232 mm
  • Length 6.575 in | 167 mm
  • Width 1.89 in | 48 mm
  • Slot to Slot 5.945 in | 151 mm

Please contact us if you are unsure about the fitment.

Description

Take-Up Mounted Unit Bearing

The HC Series Take-Up Mounted Ball Bearings provide reliable shaft support for industrial machinery, agricultural equipment, conveyors, and material handling systems. Each unit comes with an insert bearing and housing with eccentric locking collar for secure shaft attachment, easy installation, and long service life.

Part Number UCT215-48
Bore ID 3 in | 76.2 mm
Height 9.134 in | 232 mm
Width 1.89 in | 48 mm
Slot to Slot 5.945 in | 151 mm
Slot Length 4.764 in | 121 mm
Length 6.575 in | 167 mm
Adjustment Screw Bore 1.614 in | 41 mm


Applications

  • Conveyor systems
  • Agricultural machinery
  • Material handling
  • General industrial machinery
