SPHCP211-34, Plastic Pillow Block Mounted Unit Bearing, 2.125 in Bore (ID), Stainless Steel Insert Bearing: SHC211-34, Housing: P211 (P)

Out of stock
$0.00
Product details
  • Type Mounted Unit Bearings
  • Part Number SPHCP211-34
  • Housing P211 (P)
  • Insert Bearing SHC211-34
  • Bore (ID) 2.125 in | 53.975 mm
  • Height 4.92 in | 125 mm
  • Length 8.543 in | 217 mm
  • Bolt to Bolt 6.77 in | 172 mm
Description

Plastic Pillow Block Mounted Unit Bearing

The HC Series 2-Bolt Flange Mounted Ball Bearings provide reliable shaft support for industrial machinery, agricultural equipment, conveyors, and material handling systems. Each unit comes with an insert bearing and housing with eccentric locking collar for secure shaft attachment, easy installation, and long service life. The insert bearing is made of stainless steel and the housing is constructed from durable plastic, offering excellent corrosion resistance and lightweight strength for demanding applications.

Part Number SPHCP211-34
Bore ID 2.125 in | 53.975 mm
Length 8.54 in | 217 mm
Width 2.36 in | 60 mm
Height (Thickness) 4.92 in | 125 mm
Bolt to Bolt 6.77 in | 172 mm


Applications

  • Conveyor systems
  • Agricultural machinery
  • Material handling
  • General industrial machinery
