SPHCP210-30, Plastic Pillow Block Mounted Unit Bearing, 1.875 in Bore (ID), Stainless Steel Insert Bearing: SHC210-30, Housing: P210 (P)

Out of stock
$0.00
Product details
  • Type Mounted Unit Bearings
  • Part Number SPHCP210-30
  • Housing P210 (P)
  • Insert Bearing SHC210-30
  • Bore (ID) 1.875 in | 47.625 mm
  • Height 4.41 in | 112 mm
  • Length 8.032 in | 204 mm
  • Bolt to Bolt 6.26 in | 159 mm
Description

Plastic Pillow Block Mounted Unit Bearing

The HC Series 2-Bolt Flange Mounted Ball Bearings provide reliable shaft support for industrial machinery, agricultural equipment, conveyors, and material handling systems. Each unit comes with an insert bearing and housing with eccentric locking collar for secure shaft attachment, easy installation, and long service life. The insert bearing is made of stainless steel and the housing is constructed from durable plastic, offering excellent corrosion resistance and lightweight strength for demanding applications.

Part Number SPHCP210-30
Bore ID 1.875 in | 47.625 mm
Length 8.03 in | 204 mm
Width 2.24 in | 57 mm
Height (Thickness) 4.41 in | 112 mm
Bolt to Bolt 6.26 in | 159 mm


Applications

  • Conveyor systems
  • Agricultural machinery
  • Material handling
  • General industrial machinery
