SBPF205-14G, Pressed Steel 3-Bolt Mounted Unit Bearing, 0.875 in Bore (ID), Insert Bearing: SB205-14G, Housing: PF205

In stock
SKU: SBPF205-14G
Material and bore size can be selected below. Dimensions (Length × Width × Height) remain the same for all options.
$10.75
Product details
  • Part Number SBPF205-14G
  • Insert Bearing SB205-14G
  • Housing PF205
  • Bore (ID) 0.875 in | 22.225 mm
  • Length 3.74 in | 95 mm
  • Bolt Circle Diameter 2.992 in | 76 mm

Please contact us if you are unsure about the fitment.

Description

Pressed Steel 3-Bolt Mounted Unit Bearing

The SB Series 3-bolt flangette mounted bearing provide reliable shaft support for machinery and agricultural equipment. Each unit comes with an insert bearing and housing with locking set screw for secure shaft attachment, easy installation, and long service life.

Part Number SBPF205-14G
Bore ID 0.875 in | 22.225 mm
Length 3.74 in | 95 mm
Bolt Circle Diameter 2.992 in | 76 mm


Applications

  • Conveyor systems
  • Agricultural machinery
  • Material handling
  • General industrial machinery
