5209 - Angular Contact Ball Bearing

In stock
Seal Type
Please verify the ball bearing width. Open (no seal) bearings may have a different width than sealed versions.
We offer bundled pricing for all ball bearings. Discounts for packs of 2, 5, 10, 50, and 100 units are automatically applied at checkout.
$13.50
Product details
  • Type Ball Bearings
  • Part Number 5209
  • Bore (Inner Diameter) 1.772 in | 45 mm
  • Outer Diameter 3.346 in | 85 mm
  • Width 1.189 in | 30.2 mm
  • Cross Reference 3209B 2RSR, 3209-2RS, 995209, FS55509, 3209.2Z, 5209CFF, 3209-2ZJ1, 3209-2ZR, 5209.2ZJ1C3, 3209DD
Description

Premium Angular Contact Ball Bearing Design

The 5000 series angular contact ball bearings are double-row bearings designed to support combined radial and axial loads. Their precision construction provides reliable performance, high load capacity, and smooth operation in a wide range of industrial and mechanical applications.

Part Number 5209
Inner Diameter (ID) 1.772 in | 45 mm
Outer Diameter (OD) 3.346 in | 85 mm
Width 1.189 in | 30.2 mm

Cross Reference (Interchangeable Numbers)

3209B 2RSR, 3209-2RS, 995209, FS55509, 3209.2Z, 5209CFF, 3209-2ZJ1, 3209-2ZR, 5209.2ZJ1C3, 3209DD, 5209A2RS, 5209CZZ, 3209B.2RSR, 3209B.2ZR.TVH, 3209B.2ZR.TNG, 3209B.2ZR.TNH, 3209A-2ZTN9, 3209B-2ZTNG, 3209B-2ZTNH, 5209AZZ, 3209ZZ, 5209MFF, 5209E2Z, 55509, 3209B.2ZR, 5209-SBKFF, 5209A2Z



Applications

  • Electric motors
  • Pumps and compressors
  • Gearboxes and transmissions
  • Machine tool spindles
  • General industrial machinery
